CLion

CLion is a commercial JetBrains IDE for C++.

Importing the project

CLion can import a project's compilation database file, commonly named compile_commands.json. To generate the compilation database file, open the terminal, change to the Blazium root directory, and run:

scons compiledb=yes

Then, open the Blazium root directory with CLion. CLion will import the compilation database, index the codebase, and provide autocompletion and other advanced code navigation and refactoring functionality.

Compiling and debugging the project

CLion does not support compiling and debugging Blazium via SCons out of the box. This can be achieved by creating a custom build target and run configuration in CLion. Before creating a custom build target, you must compile Blazium once on the command line, to generate the Blazium executable. Open the terminal, change into the Blazium root directory, and execute:

scons dev_build=yes

To add a custom build target that invokes SCons for compilation:

• Open CLion and navigate to Preferences > Build, Execution, Deployment > Custom Build Targets

• Click Add target and give the target a name, e.g. Blazium debug.

• Click ... next to the Build: selectbox, then click the + button in the External Tools dialog to add a new external tool.

• Give the tool a name, e.g. Build Blazium debug, set Program to scons, set Arguments to the compilation settings you want (see compiling Blazium), and set the Working directory to $ProjectFileDir$, which equals the Blazium root directory. Click OK to create the tool.

  Note

  CLion does not expand shell commands like scons -j$(nproc). Use concrete values instead, e.g. scons -j8.

• Back in the External Tools dialog, click the + again to add a second external tool for cleaning the Blazium build via SCons. Give the tool a name, e.g. Clean Blazium debug, set Program to scons, set Arguments to -c (which will clean the build), and set the Working directory to $ProjectFileDir$. Click OK to create the tool.

• Close the External Tools dialog. In the Custom Build Target dialog for the custom Blazium debug build target, select the Build Blazium debug tool from the Build select box, and select the Clean Blazium debug tool from the Clean select box. Click OK to create the custom build target.

• In the main IDE window, click Add Configuration.

• In the Run/Debug Configuration dialog, click Add new..., then select Custom Build Application to create a new custom run/debug configuration.

• Give the run/debug configuration a name, e.g. Blazium debug, select the Blazium debug custom build target as the Target. Select the Blazium executable in the bin/ folder as the Executable, and set the Program arguments to --editor --path path-to-your-project/, where path-to-your-project/ should be a path pointing to an existing Blazium project. If you omit the --path argument, you will only be able to debug the Blazium Project Manager window. Click OK to create the run/debug configuration.

You can now build, run, debug, profile, and Valgrind check the Blazium editor via the run configuration.

When playing a scene, the Blazium editor will spawn a separate process. You can debug this process in CLion by going to Run > Attach to process..., typing godot, and selecting the Blazium process with the highest pid (process ID), which will usually be the running project.
